Optimised dimensions of the mattress platform
The mattress platform sections boast optimal dimensions designed in accordance with anthroprometric statistics and pressure mapping
recommendations. The Medley Ergo range offers:
• Increased comfort when sitting
• Reduced shear and friction
• Minimised risk of sliding downwards
during profiling
• Also suitable for shorter clients
Improved functionality and efficiency
The Invacare Medley Ergo range has been specially designed for quick transportation to meet the needs of
the transient working environments of Community Care provision. The Medley Ergo can be supplied on a transporter kit so the bed can easily be moved and
installed. In addition, any assembling can be done without the use of tools or technicians.
Height is no longer an issue
The flexible design of the Medley Ergo range allows the bed to be mounted at a low height, or a higher position if preferred, creating a range of working heights for the carer and transfer heights for the client. This is facilitated by the unique feature of the bed end, which enables the mattress support to be mounted in both upper and lower positions.
Technical Specifications
• Maximum user weight - 145kg
• Dimensions
- Overall length 224cm
- Overall width 102cm
- Length inside bed 208cm
- Width inside bed 90cm
• Height adjustment - 33-73cmor 40-80cm
• Backrest angle - 70°
• Thigh angle - 0-24°
• Legrest list - 0-11°
• Tilt: 11° tilt option - only practised for users under medical supervision
• Bed weight - 64kg
